Assembly 11: Staple finisher (rear)
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8148 1 1 Stapler cooling fan “Stapler cooling fan
removal” on page 372
2 40X8135 1 1 Stapler power supply unit “Stapler power supply
unit removal” on
page 372
2 40X8540 1 1 Stapler power supply unit—China “Stapler power supply
unit removal” on
page 372
3 40X8128 1 1 Stapler rear door “Stapler rear door
removal” on page 357
4 40X8458 1 1 Trapped staple access door “Trapped staple access
door removal” on
page 367
5 40X8134 1 1 Sensor (stapler pass through) “Sensor (stapler pass
through) removal” on
page 384
6 40X8138 1 1 Stapler rear door close limit switch with cable “Stapler rear cover close
limit switch removal” on
page 370
7 40X7592 1 1 Sensor (stapler rear door) “Sensor (stapler rear
cover) removal” on
page 365
7016
Parts catalog
436
