Assembly 13: Staple finisher tamper assembly
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8754 1 1 Sensor (stapler paddle HP) “Sensor (stapler paddle HP) removal”
on page 395
2 40X8754 1 1 Sensor (stapler left tamper HP) “Sensor (stapler left tamper HP)
removal” on page 394
3 40X8750 2 2 Stapler tamper drive belt “Tamper drive belt removal” on
page 389
4 40X8754 1 1 Sensor (stapler right tamper HP) “Sensor (stapler right tamper HP)
removal” on page 393
5 40X8125 2 1 Stapler tamper motor “Stapler left tamper motor removal”
on page 368 or “Stapler right tamper
motor removal” on page 369
6 40X8749 1 1 Tamper sub-assembly “Tamper sub-assembly removal” on
page 387
7016
Parts catalog
440
