Finisher jam service check
Action Yes No
Step 1
Open the rear door and check the flag of the sensor (stapler pass through).
If damaged, then replace the sensor. See “Sensor (stapler pass through)
removal” on page 384.
Remove the left cover, reseat the sensor connector on the controller card,
and then POR the machine.
Does the error remain?
Go to step 2. The problem is solved.
Step 2
Check the sensor (stapler pass through) for proper operation. Enter
Diagnostics Menu and navigate to:
FINISHER TESTS > Sensor Test
Select Pass and Media.
Does the status shown on the control panel change each time the sensor
is toggled?
Go to step 3. Replace the sensor. See
“Sensor (stapler pass
through) removal” on
page 384.
Step 3
Open the stapler service cover, reseat all connectors on the controller
card, and then POR the machine.
Does the error remain?
Replace the controller
card. See “Stapler
controller card
removal” on page
368.
If the error persists,
then go to step 4.
The problem is solved.
Step 4
Check the paper path of the stapler for obstructions.
Is it free of obstructions?
Go to step 5. Remove all
obstructions along the
paper path.
Step 5
Check the paper path for damage.
Is the paper path free of damage?
If the error remains,
then contact the next
level of support.
Replace the staple
finisher option. See
“Staple finisher option
removal” on page
352.
7016
