Charging and Starting System
90-8M0050731 MAY 2011 Page 2B-5
Flywheel/Alternator
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Alternator
2 1 Bolt (M10 x 100) (stainless steel) 75 55
3 1 Bolt (M10 x 120) (stainless steel) 54 40
4 3 Washer (0.390 x 1.00 x 0.06)
5 3 Mount
6 1 Bracket
7 3 Washer (0.406 x 1.250 x 0.089)
8 1 Bracket
9 2 Nut (M10) 54 40
10 1 Bolt (M10 x 55) 54 40
11 1 Cable assembly
12 1 Pin
13 1 Bracket
14 3 Screw (0.312‑18 x 1 in.) (stainless steel with nylon patch) 20 180 15
15 1 Spring
16 1 Belt tensioner arm assembly
17 1 Stud (M10 x 85)
18 1 Nut (M10) 20 180 15
19 1 Bushing
20 2 Washer
21 1 Pulley assembly
22 1 Screw (M10 x 35) (stainless steel) 34 25
23 1 Belt
24 1 Flywheel
25 1 Nut (0.625‑18) 170 125
26 1 Washer (0.641 x 1.250 x 0.190)
27 1 Yellow plug
28 1 Nut (M6) (stainless steel) 7 62
29 1 Washer
Tube Ref No. Description Where Used Part No.
95
2-4-C with Teflon Bushing and belt tensioner arm assembly 92-802859A 1
