Pump Unit
90-8M0050731 MAY 2011 Page 5A-33
9. Press a new ball bearing into the pinion shaft housing using the bearing installer.
Bearing Installer 91‑832016T
10. Press the pinion shaft into the pinion housing.
11. Press new seals into the pinion shaft housing, one at a time, using the seal installer. Inner seal faces in, outer seal faces out.
Fill between the seals with Special Lubricant 101.
a - Seal installer 91‑820552 1
Bearing Installer 91‑820552 1
Tube Ref No. Description Where Used Part No.
34
Special Lubricant 101 Between shaft seals 92-802865Q02
Impeller Shaft Removal
1. Remove the stator, wear ring, and impeller. Refer to Servicing the Stator, Impeller, and Wear Ring.
To Next Page
