Mercury 200 OptiMax Jet Drive Service Manual

Pump Unit
Page 5A-32 90-8M0050731 MAY 2011
5. Remove the pinion shaft outer race from the pinion shaft housing using a slide hammer.
45269
Slide Hammer 91‑34569A 1
6. Press a new outer race into the pinion shaft housing using the mandrel.
45271
Bearing Cup Installer 91‑832018
7. Remove the tapered roller bearing from the pinion shaft using the universal puller plate.
8. Press a new tapered roller bearing onto the pinion shaft using the pinion shaft taper roller bearing installer.
45272
Universal Puller Plate 91‑37241
Bearing Installer 91‑827983T
