Maintenance
90-8M0050731 MAY 2011 Page 1B-11
• Cracks or deterioration in the rubber portion of the belt.
• Belt surfaces rough or uneven.
• Signs of wear on edges or outer surfaces of belt.
Belt Tensioner Idler Pulley Lubrication
Lubricate through the fitting with 2‑4‑C with Teflon.
Tube Ref No. Description Where Used Part No.
95
2-4-C with Teflon Tensioner pulley grease fitting 92-802859A 1
Drive Housing Lubricant
Draining Lubricant
NOTE: When draining the drive housing lubricant, visually check for water in the lubricant. It may have settled to the bottom and
will drain before the lubricant or it may have mixed with the lubricant, giving it a milky color. In either case, have the drive housing
checked by your authorized Mercury Marine dealer. Water in the lubricant can cause premature gear or bearing failure or, in
freezing weather, damage to the drive housing.
a - Drive housing (bottom view)
b - Fill/drain screw
c - Vent screw
1. Place a drain pan below the drive.
2. Remove the fill/drain screw.
3. Remove the vent screw to drain the lubricant.
