General Information
90-8M0050731 MAY 2011 Page 1C-11
Mercury Jet Pump Starboard View
a - Reverse gate
b - Shift cable assembly
c - Hull
d - Shift cable assembly/through‑the‑hull fitting
e - Water intake
f - Wear ring
g - Trim plate
h - Stator
Mercury Jet Pump Port View
a - Reverse gate
b - Steering cable assembly
c - Hull
d - Steering cable assembly/through‑the‑hull fitting
e - Water intake
f - Trim plate
g - Forward stop
h - Rudder
45362
a
b
d
e
f
g
h
c
a
b
d
e
f
g
h
c
45363
