Specifications
90-8M0050731 MAY 2011 Page 1A-3
Ignition Specifications
Ignition Specifications
Type Digital inductive
Spark plug NGK IZFR6J
Spark plug gap 1.1 mm (0.043 in.)
Maximum timing Not adjustable; PCM controlled
Idle timing Not adjustable; PCM controlled
Throttle position sensor
At idle 0.4–1.3 VDC
At WOT 4.0–4.7 VDC
Charging and Starting Specifications
Charging and Starting Specifications at 21 °C (70 °F)
Alternator output (regulated)
Output at the battery at 2000 RPM 28–36 A
Output at the alternator at 2000 RPM 42–48 A
Voltage set point 14.5 ± 0.25 volts
Regulator current draw
1.
Ignition switch "OFF" 0.585 mA
Ignition switch "ON" 150.0 mA
Starter draw
Under load 200 A
No load 65 A
Average engine RPM when cranking 300–325 RPM
Starter solenoid current at 12.6 volts
Pull in coil 40 A
Hold in coil 10 A
Start solenoid current draw 4 A
Starter brush length (minimum) 6.35 mm (0.25 in.)
Battery rating (minimum)
Marine cranking amperes 1000
Cold cranking amperes 800
Ampere hour (Ah) 180
1. All model alternator specifications require an amperage draw of less than 1.0 mA with the ignition key in the "OFF" position and an amperage draw
of not more than 350.0 mA with key in the "ON" position.
