Specifications
Page 1A-4 90-8M0050731 MAY 2011
Fuel Specifications
Fuel Specifications
Fuel Gasoline with oil injection
Recommended gasoline Unleaded 87 octane minimum
Recommended oil
Direct fuel injected (DFI) 2‑cycle Outboard Oil or
Premium Plus 2‑cycle TC‑W3 Outboard Oil
Gasoline/oil ratio
At idle 300–400:1
At wide‑open throttle 40:1
Fuel Lift Pump Specifications
Fuel Lift Pump Specifications
Fuel lift pump pressure at idle
Normal 6.9–13.8 kPa (1–2 psi)
Maximum 68.9 kPa (10 psi)
Fuel lift pump amps 1–2 A
Fuel Rail Specifications
Fuel System Specifications
Fuel pressure 751.5 ± 14 kPa (109 ± 2 psi)
Air pressure 655 ± 14 kPa (95 ± 2 psi)
Tracker valve spring pressure 103.5 kPa (15 psi)
Fuel injector ohm resistance 1.8 ± 0.1 Ω
Direct injector ohm resistance 1.3 ± 0.3 Ω
Direct injector color Gray
Fuel rail water cooling None
Fuel System Specifications
Fuel Lift Pump Specifications
Fuel lift pump pressure at idle
Normal 6.9–13.8 kPa (1–2 psi)
Maximum 69 kPa (10 psi)
Fuel lift pump amps 1–2 A
Low‑Pressure Boost Pump Specifications
Low‑pressure boost pump pressure at idle 41–62 kPa (6–9 psi)
Low‑pressure boost pump amps 1–2 A
