Jet Installation
Page 1D-20 90-8M0050731 MAY 2011
3. Fasten the negative (–) battery cable to the grounding bolt located on the engine block below the starter motor. Seal the
connection with Liquid Neoprene.
a - Positive battery cable attaching location
b - Negative battery cable attaching location
Tube Ref No. Description Where Used Part No.
25
Liquid Neoprene Battery cable connections 92- 25711 3
Remote Harness Connection
Connect the remote 14 pin wiring harness to the 14 pin connector located on the engine.
a - 14 pin connector
b - Remote 14 pin wiring harness
