Mercury 200 OptiMax Jet Drive Service Manual

General Information
90-8M0050731 MAY 2011 Page 1C-9
200 OptiMax SportJet Powerhead Aft View
1 - 80 psi air hose
2 - Water pressure sensor
3 - SmartCraft connector
4 - Cover
5 - Expansion chamber
6 - Expansion chamber coolant hose
7 - Exhaust pipe coolant hose
8 - T‑fitting
9 - Water bypass hose
10 - Air compressor inlet
11 - Air compressor
