Jet Installation
90-8M0050731 MAY 2011 Page 1D-17
2. Remove the cover by lifting off from the back of the engine.
a - Flywheel cover
b - Retaining strap
Installation
1. Lower the cover opening onto the air plenum intake flange. Tilt the cover side to side until the cover slides down onto the
intake flange.
2. Push the cover down onto the alignment pins and onto the air intake tube for the air compressor.
a - Air plenum intake flange
b - Air intake tube for the air compressor
3. Attach the retaining strap to the cover.
a - Retaining strap
Installing the Throttle Cable
1. Shift the remote control into the neutral position.
