Charging and Starting System
90-8M0050731 MAY 2011 Page 2B-7
Starter Motor Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Starter motor assembly
2 2 Through bolt 12.5 110
3 1 Solenoid kit
4 1 Gear kit
5 1 Nut (M8) (stainless steel) 9 80
6 1 Lockwasher (0.312)
7 1 Nut (M5) (stainless steel) 2.5 22
8 1 Lockwasher (M5)
9 1 Screw and lockwasher (0.250‑20 x 0.625) (stainless steel) 11 97
10 1 Cable assembly (6.0 in.) (black)
11 1 Rubber stop
12 2 Starter motor collar
13 1 Start in gear caution decal
14 1 High voltage warning decal
