Fuel Pump

90-8M0050731 MAY 2011 Page 3A-5

Fuel Pump System Components

Ref. No. Qty. Description

Torque

Nm lb‑in. lb‑ft

1 3 Bushing

2 3 Grommet

3 3 Screw (M6 x 16) 11.5 102

4 1 Screw (M6 x 35) 11.5 102

5 1 Hose

6 1 Hose

7 A/R Hose clamp (18.3 mm)

8 1 Lift pump and filter

9 11 Bracket

10 1 Wire assembly

11 1 Bracket kit

12 1 Grommet

13 1 Low‑pressure fuel pump (boost pump)

14 1 90° elbow

15 1 O‑ring

16 1 Fitting

17 1 O‑ring

18 1 Hose

19 1 Water sensor

20 3 Screw (M8 x 35) and washer 16 142

21 1 Vapor separator tank (VST) assembly

Mercury 200 OptiMax Jet Drive Service Manual
