Direct Fuel Injection
90-8M0050731 MAY 2011 Page 3B-5
Pintle Test Fixture 91‑899883A08
35783
Used with a dial indicator to test the operating movement of a direct injector pintle.
Dial Indicator 91‑ 58222A 1
9479
Used to obtain a variety of measurements including gear backlash, pinion gear
location, and TDC.
Seal/Teflon Ring Installation Tool 91‑851980‑‑3
8285
Aids in the installation of Teflon seals on direct injectors
Seal/Teflon Ring Sizing Tool 91‑851980‑‑2
8286
Compresses the Teflon seal on direct injectors after seal installation
