Direct Fuel Injection

90-8M0050731 MAY 2011 Page 3B-7

Vapor Separator Components

Ref. No. Qty. Description

Torque

Nm lb‑in. lb‑ft

1 1 Cover kit

2 1 Straight fitting

3 1 90° elbow fitting

4 1 Seal

5 1 Pump outlet fitting kit

6 1 O‑ring

7 7 Screw and washer (8‑32 x 0.750 in.) 3.5 31

8 1 Gasket

9 1 Float kit

10 1 Pin

11 1 Needle valve

12 1 Screw (8‑32 x 0.187 in.) 1 9

13 1 Pump kit

14 1 Sleeve

15 1 Bowl kit

16 1 Seal

17 1 Plug kit

18 1 O‑ring

19 2 Elbow fitting

20 1 Elbow fitting

21 1 Elbow fitting

22 1 Fuel filter kit

23 1 Water sensing probe

Mercury 200 OptiMax Jet Drive Service Manual
