Direct Fuel Injection
90-8M0050731 MAY 2011 Page 3B-11
Air Handler Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Adapter plate
2 1 Gasket
3 1 Gasket
4 6 Reed block assembly
5 12 Screw (1/4‑20 x 7/8 in.) 11.5 102
6 1 Oil pump
7 6 Bushing
8 6 Grommet
9 3 Screw (M8 x 35) 16 142
10 6 Washer (0.344 x 1.00 x 0.063 in.)
11 1 Air plenum kit
12 3 Screw (M8 x 30) 16 142
13 1 Manifold air temperature (MAT) sensor 16 142
14 1 O‑ring
15 2 Screw (M4 x 16) 2.5 22
16 1 Throttle body assembly
17 1 O‑ring
18 4 Screw (M6 x 40) 7.5 66
19 1 Screw (M6 x 16) 4.5 40
20 1 Manifold absolute pressure (MAP) sensor
21 1 MAP sensor bracket
22 1 Bracket
