Direct Fuel Injection
90-8M0050731 MAY 2011 Page 3B-13
Fuel Rail Components (S/N 0T178500 and Above)
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Port fuel rail
2 1 Starboard fuel rail
3 4 Clamp
4 20 Screw (M5 x 10) 8 71
5 2 Schrader valve assembly
6 1 O‑ring kit
7 2 Brass cap
8 1 Port plug
9 1 Clamp
10 4 Clamp
11 6 Fuel injector
12 1 O‑ring kit
13 1 O‑ring kit
14 2 Clamp
15 1 Clamp
16 1 Air regulator
17 1 O‑ring kit
18 2 Clamp
19 4 Screw (M5 x 16) 8 71
20 1 Cover
21 1 Spring
22 1 Diaphragm assembly
23 2 O‑ring
24 1 Starboard plug
25 1 Fitting
26 1 O‑ring kit
27 6 Direct injector
28 6 Seal kit
29 4 Stud (M10 x 91)
30 4 Nut (M10) 45 33
31 6 Injector washer
32 4 Clip
Tube Ref No. Description Where Used Part No.
110
4-Stroke 10W-30 Outboard
Oil
Direct injector and injector washer 92-858045K01
To Next Page
