Mercury 200 OptiMax Jet Drive

Direct Fuel Injection
90-8M0050731 MAY 2011 Page 3B-15
Fuel Hose Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Hose (21.6 cm [8.5 in.])
2 1 Fuel return hose assembly
3 1 Fuel supply hose assembly
4 1 O‑ring kit
5 1 Hose
6 1 Hose
7 2 Sleeve
8 8 Hose clamp (18.3 mm)
