Direct Fuel Injection
90-8M0050731 MAY 2011 Page 3B-19
Air Compressor Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Air compressor kit
2 1 Body
3 1 End cap assembly
4 1 Retaining ring
5 1 O‑ring
6 1 O‑ring
7 4
Carbon steel screw (M6 x 20) 17 150
Stainless steel screw (M6 x 20) 11.5 102
8 1 Connecting rod assembly
9 1 Bearing
10 1 Bearing
11 1 Piston assembly
12 1 Oil scraper ring
13 1 Top ring
14 1 Oil ring
15 1 Wrist pin
16 1 Piston with wrist pin
17 2 Lockring
18 1 Reed plate assembly
19 2 O‑ring
20 1 O‑ring
21 1 Seal
22 1 Compressor head kit
23 1 Fitting
24 4 Screw (M8 x 14) 27 20
25 1 Temperature sensor
26 1 Retainer
27 1 Screw (M8 x 14) 27 20
28 1 O‑ring
29 1 Fitting
30 2 Check valve fitting
31 1 Fitting
32 1 Fitting
33 1 Instruction decal
34 6 Screw (M6 x 12) 19 168
35 1 Grommet
36 1 45° elbow fitting
37 2 Hex flange screw (M10 x 25)
First 1.5 13
Final 56 41
38 2 Stud (0.312‑18/0.324‑24 x 4.190)
