Oil Injection
90-8M0050731 MAY 2011 Page 3C-5
Oil Injection Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Tubing (61 cm [24 in.])
2 1 Tubing (47 cm [18.5 in.])
3 1 Tubing (42 cm [16.5 in.])
4 1 Tubing (62.2 cm [24.5 in.])
5 2 Tubing (68.6 cm [27 in.])
6 6 Check valve
7 AR Cable tie (14 cm [5.5 in.])
8 AR
Cable tie (20.3 cm [8 in.])
Cable tie (10 cm [4 in.])
9 1 Hose (61 cm [24 in.])
10 1 Hose (81.3 cm [32 in.])
11 1 Check valve (to block)
12 1 Fitting
13 1 Hose (15.3 cm [6 in.])
14 2 Cap
15 1 Hose
16 2 Connector
17 1 In‑line oil filter
18 1 Hose (5 cm [2 in.])
19 1 Reservoir assembly
20 1 Reservoir decal
21 3 Grommet
22 3 Washer
23 3 Screw (0.312‑18 x 1.250)
24 3 Bushing
25 1 Switch assembly
26 1 Screw (0.164‑18 x 3/8)
27 1 Washer
28 1 Clamp
29 1 Hose (12 cm [4.75 in.])
30 1 Connector
To Next Page
