Mercury 200 OptiMax Jet Drive

Powerhead
90-8M0050731 MAY 2011 Page 4A-11
Exhaust Manifold and Exhaust Plate
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Gasket
2 1 Exhaust divider plate assembly
3 1 Seal (12.5 in.)
4 16 Screw and washer (0.312‑18 x 1.50 in.) 18 160 13
5 2 Screw (0.312‑18 x 1.00 in.) 18 160 13
6 1 Relief valve cover
7 4 Screw (0.312‑18 x 1.375 in.) 15 133
8 1 Gasket
9 1 Screw (0.312‑18 x 1.75 in.)
10 1 Plug (0.50‑14 in.)
Tube Ref No. Description Where Used Part No.
7
Loctite 271 Threadlocker Divider plate screw threads 92-809819
