Powerhead
90-8M0050731 MAY 2011 Page 4A-13
Cylinder Head
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1
1 Cylinder head assembly (port)
1 Cylinder head assembly (starboard)
2 24 Screw (0.375‑16 x 2.75 in.)
First 40.5 30
Final Turn an additional 90°
3 4 Dowel pin (0.25 x 0.625 in.)
4 2 Gasket
5 2 Cover
6 6 Seal
7 4 Screw (M6 x 25 mm) 13.5 120 10
8 2 Temperature sensor assembly 17 150 12
9 2 O‑ring (1.78 mm x 0.08 mm)
10 2 Seal
Tube Ref No. Description Where Used Part No.
14
2-cycle Premium Outboard
Oil
Cylinder head screw threads and face 92-858021K01
To Next Page
