Mercury 200 OptiMax Jet Drive Service Manual

Powerhead
90-8M0050731 MAY 2011 Page 4A-37
19. Remove the oil seals from the end caps with a hammer and an appropriate tool.
a - O‑ring
b - Seal
20. Install the crankshaft onto a powerhead stand and inspect the sealing rings.
IMPORTANT: Do not remove the crankshaft sealing rings unless the sealing ring is broken.
Powerhead Stand 91‑ 30591T 1
21. Remove the retainer ring holding the main bearing races together.
a - Sealing rings (9)
b - Retainer ring (2)
c - Main bearing (2)
a
b
8635
a
b
b
47365
c
c
