Pump Unit
90-8M0050731 MAY 2011 Page 5A-9
Nozzle and Rudder Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Gate kit
2 1 Lockwasher
3 1 Anode
4 1 Screw (M6 x 20) 8 71
5 2 Pivot bushing
6 2 Trilobe pin
7 1 Clevis pin
8 1 Washer
9 1 Cotter pin
10 1 Reverse gate decal (Power by Mercury)
11 2 Special pivot bolt 68 50
12 1 Rudder kit
13 2 Pivot bushing
14 1 Lockwasher
15 1 Anode
16 1 Screw (M6 x 20) 8 71
17 1 Swivel end kit
18 1 Washer
19 1 Screw and nut kit
20 1 Nut (1/4‑20)
21 2 Flange screw (M10 x 45) 47 35
22 1 Anode with bushing in casting
23 1 Screw (M8 x 25)
24 1 Stop
25 2 Special washer
26 2 Flange screw (M10 x 35) 47 35
27 1 Nozzle assembly with pivot bushing
28 1 Fitting
29 1 Siphon hose
30 1 Screw (M8 x 30) 13.5 120
31 1 Washer
32 1 Reverse gate stop
33 4 Screw (M10 x 150) 47 35
34 4 Washer
35 1 Stator assembly
36 2 Plug (1/4‑18)
37 2 Bushing
38 1 Seal
39 1 Seal protector
40 1 Tab washer
