Pump Unit
90-8M0050731 MAY 2011 Page 5A-13
Jet Drive Housing Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Housing
2 1 Siphon drain fitting (1/8‑27)
3 4 Stud (M10 x 55)
4 2 Oil seal
5 1 Ball bearing
6 1 Snap ring
7 2 Drain screw (3/8‑16 x 1/4) 5.6 50
8 2 Sealing washer
9 1 Gasket (jet drive housing to top cover)
10 1 Pump mount grommet
11 4 Brass nut (M10) 47.5 35
12 1 O‑ring (0.489 x 0.070)
13 1 O‑ring (0.796 x 0.139)
14 1 O‑ring (0.412 x 0.210)
15 1 Water tube
16 1 Inlet screen (6 tines)
17 Option Inlet grate kit
18 1 Spring
19 1 Tines
20 1 Frame
21 2 Screw with nylon patch (M6 x 20) 8.5 75
22 2 Special pivot screw 8.5 75
23 2 Screw (M8 x 25) 23 17
24 Option Rock grate kit (12 tines)
25 2 Screw with nylon patch (M6 x 20)
26 2 Screw (M8 x 25)
27 2 Nut (M8) 18 159
28 2 Washer
29 2 Washer
30 1 Trim plate
31 2 Screw (M8 x 35)
32 1 Ride plate kit
33 16 Screw with nylon patch (M6 x 20) 8.5 75
34 1 Ride plate seal kit
Tube Ref No. Description Where Used Part No.
7
Loctite 271 Threadlocker Jet drive housing studs, special pivot screws 92-809819
66
Loctite 242 Threadlocker Ride plate screws, inlet screen screws and rock grate screws 92-809821
87
High Performance Gear
Lubricant
Jet drive housing 92-858064K01
