Mercury 200 OptiMax Jet Drive Service Manual

Ignition
90-8M0050731 MAY 2011 Page 2A-7
Electrical Plate Hardware
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Electrical plate
2 2 Clip
3 2 Clip
4 2 Clip
5 4 Screw (M6 x 10) 4 35
6 4 Grommet
7 4 Bushing
8 2 Bushing
9 2 Stud (M6 x 50)
10 2 Washer
11 2 Nut (M6) 7 62
12 3 Cable tie clip
13 2 Clip
14 1 Clip
15 AR Cable tie
16 1 Cover
17 1 Sleeve
18 1 Flange screw (M6 x 14) 7 62
