098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 159
Chapter 5
SyncServer S6x0 CLI Command Set
5 IRIG - Slot A “–” = OK
“I” = Fault
Indicates OK when the Slot A-J1 input is
qualified for time. This connector
supports all IRIG inputs.
This is equivalent to Green
indication for Slot A - J1 on
Dashboard>Timing >Timing
Reference row.
Note that disabling of AJ1 will also
generate “I”.
If this input is configured for
PPS/10MPPS this alarm will react
based on the condition of the input
This only applies to slot A.
6 External Input
Reference -
Slot B
“–” = OK
“A” = Fault
Indicates OK when the Slot A - J2 input
is qualified for frequency. This connector
supports only frequency inputs
(1/5/10MHz). This is equivalent to Green
indication for Slot A - J2 in WebGUI
Dashboard > Timing > Holdover
References row.
Note that:
Disabling of Slot A - J2 will also
generate “A”.
This only applies to slot A.
7 Primary Power “–” = OK
“W” = Fault
The Primary Power indicator reports
“OK” when the power supply voltages
are normal. It reports “Fault” when the
power supply voltages exceed +/-10%
of nominal supply regulation.
While the Primary Power indicator
reports a fault, all outputs from the
SyncServer S6x0 are unreliable and
should not be used unless a Secondary
Power supply is available and operating
normally.
When seen from the rear of the
SyncServer S6x0, the Primary Power
indicator corresponds to the power
supply module in the lowest, left-most
bay.
Table 5-3. F73 Alarm Indicators
Syntax Alarm Indicators Description
