Chapter 1 Overview
Functional Description
Time Inputs
The SyncServer S6x0 can use GNSS, NTP, and IRIG as external input references
(depending on model and configuration). The NTP signals use the RJ45 (1 - 4)
connectors on the rear panel. The GNSS reference uses a BNC connector on the
rear panel. The IRIG signal uses a BNC connector (J1) on the optional Timing I/O
module on the rear panel, as described in Table 1-1.
Frequency Inputs
The SyncServer S6x0 can use either 1PPS, 10 MPPS, 10 MHz, 5 MHz, or 1 MHz as
external frequency input references. The 1PPS/10 MPPS use the J1 BNC and the
10 / 5 / 1 MHz signals use a BNC connector (J2) on the Timing I/O module on the
rear panel, as described in Table 1-1.
Frequency and Timing Outputs
The SyncServer S6x0 can provide NTP,10 / 5 / 1 MHz, 1PPS, IRIG, or TOD output
signals. The NTP signals use the RJ45 (1 - 4) connectors on the rear panel. The
serial TOD output connects to a DB9 connector (DATA/SERIAL) on the rear panel.
The IRIG, PPS, 10 MPPS, and 10 / 5 / 1 MHz signals use BNC connectors (J3 - J8)
on the Timing I/O module on the rear panel. A 1PPS output is also available using a
BNC connector (1PPS) on the rear panel.
Table 1-1. Timing Input/Output Module
Config.
Input BNCs Output BNCs
J1 J2 J3 J4 J5 J6 J7 J8
Standard
IRIG B AM
124 or 1PPS
10 MHz IRIG B AM 10 MHz IRIG B B004
DCLS
1PPS off off
Flex Port
Option
A000
A004
A134
IRIG B000
IRIG B004
IRIG B120
IRIG B124
IRIG E115
IRIG E125
IEEE 1344
C37.118.1a
-2014
1PPS
10 MPPS
1 MHz
5 MHz
10 MHz
FlexPort J3-J8 Software Selectable Outputs per BNC (Configured via
the web interface):
a) Pulse:
i) Fixed Rate 10/5/1MPPS, 100/10/1/kPPS, 100/10/1/0.5PPS, 1PPM
ii) Programmable Period: 100 ns to 2 sec, step size of 10 ns
b) Timecode: IRIG B 000/004/1344 DCLS, 120/124/1344 AM
• IRIG A 004/134
• IRIG B 000/001/002/003/004/005/006/007/ C37.118.1a-2014/
1344 DCLS
• IRIG B 120/122/123/124/125/126/127/1344 AM
• IRIG E 115/125
• IRIG G 005/145
• NASA 36 AM/DCLS, 2137, XR3
c) Sine: 1/5/10 MHz
BNC-by-BNC output phase adjustment for timecodes and pulses
