098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 285
Appendix B Specifications and Factory Defaults
GNSS Antenna Kits Specifications
GNSS Lightning Arrestor Specifications
Table B-25. Lightning Arrestor Specifications
Characteristic Specification
Type DC Pass
Mount Type Bulkhead Mount
PIM Rated N
Standards CE Compliant, RoHS
Compliant
Connector N
Surge Side Connector Bi-Directional N
Protected Side Connector Bi-Directional N
Frequency Range dc to 5 GHz
Turn On Voltage 150 Vdc (spark over)
RF Power 25 W
VSWR <1.2 dB to 1
Insertion Loss <0.1 dB
Protocol/Application Gas tube, DC pass RF coaxial
protection for dc to 5 GHz
