Antenna Kits Overview
Antenna Kits Accessories
Lightning Arrestor
Microsemi offers the lightning arrestor for installations that require antenna coaxial
lead-in protection. The lightning arrestor passes DC power and frequencies in the
1.5 GHz range with L1 GNSS antennas. In most installations, the lightning arrestor
mounts near the point at which the antenna lead enters the facility. See the GNSS
Lightning Arrestor Specifications, on page 285 for specifications.
450 ft. Antenna Cable 060-15202-450 545
500 ft. Low Loss Antenna Cable 060-15202-500 600
750 ft. Low Loss Antenna Cable 060-15202-750 900
900 ft. Low Loss Antenna Cable 060-15202-900 1080
Kit:
 GPS/GLONASS Antenna (112-00079-000)
 Mounting Bracket (193-00044-000)
 Adapter cable for chassis (060-15202-004)
093-15202-001 46
Kit:
Lightning Arrestor (112-43400-00-3) with 25 ft. cable
093-15202-002 31
Kit:
Lightning Arrestor (112-43400-00-3) with 25 ft. low
loss cable
093-15202-003 30
Kit:
1:4 GPS Splitter With Two (2) x 3 ft. cables
093-15202-004 44
Inline Amplifier (112-15202-001) with adapter 093-15202-005 1
Kit:
 GPS/GLONASS/BeiDou Antenna
(112-15202-003)
 Mounting Bracket (193-00044-000)
 Adapter cable for chassis (060-15202-004)
093-15202-006
34
1
(28 ns for antenna only)
Kit:
GPS/GLONASS/BeiDou 1:4 splitter (112-00118-000)
with Two (2) x 3 ft. cables
093-15202-007 6
(2 ns for splitter only)
Note:
1
16 ns additional delay for BeiDou
Table C-1. GNSS Antenna Kits & Accessories
Antenna Kit Part Number Total Delay (ns)
