098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 189
Chapter 6 Provisioning
Provisioning Input References
Provisioning Sine Wave Inputs on Timing I/O Module
Sine wave inputs are available for Port J2 of the Timing I/O module with the
SyncServer S650.
Provisioning PTP Client Input
The LAN2 - LAN6 ports can be configured as PTP Client inputs with the SyncServer
S650.
Note: A Flex Port Option license is required for full configurability of
all BNC connectors on the Timing I/O module.
Table 6-8. Configure Sine Wave Inputs on Timing I/O Module
Method Steps Notes
Web Interface Option Slot A > Timing I/O Card
1. For input J2, use dropdown box to
select “Sine” or Off.
2. If sine is selected, use the
dropdown box to select the
frequency of the sine wave input:
- 10 MHz
- 5 MHz
- 1 MHz
3. Click the Apply button.
CLI n/a n/a
Front Panel n/a n/a
Note: A PTP Input Option license is required for this feature.
