Appendix B Specifications and Factory Defaults
Specifications
NTP Input
PPS Input
10M PPS Input
10M PPS input is available with the Optional Timing I/O Module.
Table B-8. SyncServer S6x0 NTP Input Signal Specifications
Parameter Specification
Connector Type RJ45
Connector Label 1, 2, 3, 4
Table B-9. SyncServer S6x0 PPS Input Signal Specifications
Parameter Specification
Signal Type TTL, rising edge active
Impedance 50 or high impedance (> 50 k )
Connector Type BNC
Connector Label J1
Table B-10. SyncServer S6x0 PPS Input Signal Specifications
Parameter Specification
Signal Type < 0.8 V for logic 0,
> 2 V for logic 1
Impedance 50 or high impedance (> 50 k )
Connector Type BNC
Connector Label J1
