098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 275
Appendix B Specifications and Factory Defaults
Specifications
10MHz, 5MHz, 1MHz Input
The 10MHz, 5MHz, and 1MHz inputs are available with the Optional Timing I/O
Module.
Timing Accuracy for Inputs
Table B-12 lists the expected timing accuracy when using different input references.
Table B-11. SyncServer S6x0 10/5/1 MHz Input Signal Specifications
Parameter Specification
Signal Type Sine Wave
Amplitude 1 Vpp to 8 Vpp
Impedance 50 
Connector Type BNC
Connector Label J2
Table B-12. Timing Accuracy to Reference
Reference
Timing Accuracy to
Reference
Comments
GPS 15 ns rms to UTC (USNO)
IRIG AM
A13x ± 5 s10 kHz
B12x ± 10 s1 kHz
E11x ± 1 ms 100 Hz
E12x ± 10 s1 kHz
G14x ± 5 s 100 kHz
NASA 36 AM ± 10 s1 kHz
XR3 AM ± 10 s 250 Hz
2137 AM ± 10 s1 kHz
IRIG DCLS
A00x ± 100 ns
B00x ± 100 ns
E00x ± 100 ns
