098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 281
Appendix B Specifications and Factory Defaults
Specifications
ULPN Module Output Signal Specifications
The ULPN outputs are available with the Optional ULPN Module.
Table B-21. SyncServer S6x0 ULPN Module Output Signal Specifications
Parameter Specification
Phase Noise
1 Hz
10 Hz
100 Hz
1 kHz
10 kHz
100 kHz
–112 dBc/Hz
–135 dBc/Hz
–150 dBc/Hz
–158 dBc/Hz
–160 dBc/Hz
–160 dBc/Hz
Allan Deviation
1 s
10 s
100 s
<4.5 × 10
–13
<9.5 × 10
–13
<5.0 × 10
–12
Output Level 13 dBm ± 1 dB
Channel Isolation 100 dB at 10 MHz
Connector type BNC male
Connector Label J1 - J8
Impedance 50 
Table B-22. Holdover Performance
Oscillator
Holdover - 24 Hour
(sec)
Standard 400
OCXO 25
Rubidium <1
