284 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Appendix B Specifications and Factory Defaults
GNSS Antenna Kits Specifications
This wide-band antenna is a precision high gain GNSS antenna covering the
BeiDou B1, Galileo E1, GPS L1, GLONASS L1, and SBAS (WAAS, EGNOS,
QZSS, and MSAS) frequency band (1557 MHz to 1606 MHz). It provides very
circular polarized signal reception through the entire bandwidth of the antenna,
thereby providing superior multipath signal rejection. The antenna has a three stage
low noise amplifier, comprised of one input LNA per feed, a mid section SAW to filter
the combined output, and a final output gain stage. An additional pre-filter provides
extra strong protection from near frequency and strong harmonic signals. An
L-bracket for pole mounting and 3-foot BNC(m) to N(f) cable is also included.
.
Table B-24. Wideband GNSS Antenna with Internal Low-Noise Amplifier Specifications
Characteristic Specification
Mechanical
Diameter 66.5 mm
Height 21 mm
Weight 150 grams
Environmental
Operating Temperature -40 to +85 C
Environmental IP67, CE, REACH, and RoHS compliant
Salt Fog / Spray MIL-STD-810F Section 509.4
Electrical
2 dB Bandwidth 47 MHz
Antenna Gain (with 100
mm ground plane)
4.25 dBic
Axial Ratio <2 dB typical, 3 dB max
Filtered LNA Frequency 1559 to 1606 MHz
Gain 40 dB minimum
Out-of-Band Rejection
<1500 MHz
>1640 MHz
>50 dB
>70 dB
VSWR (at LNA output) <1.5:1
Noise Figure 3 dB typical
Supply Voltage Range +2.5 to 16 VDC nominal
(12 VDC recommended maximum)
Supply Current 19 mA maximum at 85°C
