098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 231
Chapter 6 Provisioning
Provisioning for SNMP
Provisioning to Generate v3 Traps
Updating v2 Communities
Table 6-26. Provisioning to Generate v3 Traps
Method Steps Notes
Web Interface Network > SNMP Traps
1. Enter IP address of SNMP manager
2. Select SNMPv3
3. Enter SNMPv3 user name
4. Enter auth password
5. Select MD5 or SHA for auth
6. Enter privacy phrase
7. Click "Save"
For SNMPv3 traps,
both a user and a
trapuser need to be
configured identically,
depending on the
SNMP trap manager.
In addition, the SNMP
manager should use
the specified
user/trapuser to
connect to the
SyncServer S6x0.
This will ensure that a
SNMPv3 trap will be
successfully received
by the manager using
the corresponding
trapuser username.
CLI n/a
Front Panel n/a
Table 6-27. Adding / Removing v2 Communities
Method Steps Notes
Web Interface Network > SNMP
1. Update user / community names
2. Click "Save"
All character except
(<), (&), (>), ("), (') are
accepted for SNMPv2
community names.
CLI n/a
Front Panel n/a
