224 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Chapter 6 Provisioning
Provisioning Outputs
Provisioning Outputs on Timing I/O Module
The standard configuration offers a broad yet fixed selection of signal I/O. J1 is
dedicated to time code and rate inputs, J2 to sine wave inputs, and J3-J8 to mixed
signal outputs. See Table 1-1 for the standard Timing I/O Module configuration.
The FlexPort™ Technology option enables the 6 output BNCs (J3-J8) to output any
supported signal (time codes, sine waves, programmable rates, etc.) on all
configurable ports via the secure web interface.
Table 6-20. NMEA183 Output Format Details
Format Description
ZDA
All fields are updated except for timezone fields, which are always 00.
$GP, $GL, and $GB are used to indicate GPS, Glonass and Beidou respectively.
Example:
*$GPZDA,235626,29,11,2016,00,00*40
GGA
All fields are updated except for the 2 DGPS fields, which are NULLed.
$GP, $GL, and $GB are used to indicate GPS, Glonass and Beidou respectively.
Example:
$GPGGA,235626,3724.7719,N,12156.8643,W,1,14,0.8,14.3,M,-29.8,M,,*41
GSV
All fields are updated.
$GP, $GL, and $GB are used to indicate GPS, Glonass and Beidou respectively.
Example:
$GPGSV,4,1,23,1,46,231,45,3,58,319,46,4,165,0,0,9,2,265,0*74
$GPGSV,4,2,23,11,21,219,38,14,35,58,43,16,9,151,39,22,77,321,47*77
$GPGSV,4,3,23,23,35,277,47,25,7,39,33,26,24,125,50,31,52,54,43*41
$GPGSV,4,4,23,32,10,72,36*78
$GLGSV,3,1,23,2,20,99,23,3,58,46,49,4,35,322,44,12,21,31,0*55
$GLGSV,3,2,23,13,63,78,46,14,38,174,41,15,2,192,35,18,5,228,43*5F
$GLGSV,3,3,23,19,19,277,48,20,10,330,32*68
RMC
All fields are updated except for speed and course, the 2 magnetic variation field,
which are all NULLed.
$GP, $GL, and $GB are used to indicate GPS, Glonass and Beidou respectively.
Example:
$GPRMC,235626,V,3724.7719,N,12156.8643,W,,,291116,,,A*7D
Note: The SyncServer S6x0 uses IRIG 1344 version
C37.118.1-2011. Control bits 14 - 19 will always be zero, and the
encoded IRIG time will be UTC (if using an input 1344 IRIG as the
reference the 2011 rules are applied to get that value). Hence, any
code receiving S6x0 IRIG 1344 output should work regardless of
which version they are decoding (since there is nothing to add or
subtract).
