188 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Chapter 6 Provisioning
Provisioning Input References
Table 6-7. Configure IRIG or Pulse Inputs on Timing I/O Module
Method Steps Notes
Web Interface Option Slot A > Timing I/O Card
1. In the section of the form labeled
“J1 Input”, use dropdown box to
select the input signal category of
interest: Timecode, “Pulse”, or Off.
2. For TimeCode, use the dropdown
box to select the type of IRIG
input:
- DCLS, without YR
- DCLS, with YR
- 1kHz, without YR
- 10kHz, with YR
- 10kHz, without YR
- 1kHz, with YR
- B1344, DCLS
- B1344, 1kHz
- 100Hz, with YR
- C37.118.1 (DCLS)
3. For Pulse, use the dropdown box
to select 1PPS or 10MPPS.
4. Click the Apply button.
Configure IRIG Input on
J1
For IRIG 1344, the code
performs a subtraction
using control bits 14 - 19
from the supplied IRIG
time with the expectation
that this will produce UTC
time. This aligns with the
C37.118.1-2011 definition.
Web Interface Timing > Input Control
1. In the Manual IRIG Year Input
section near the bottom of the
window, enter the Year.
2. Click the Apply button.
Manually Configure Year
for IRIG Input on J1
Web Interface Option Slot A > Timing I/O Card
1. In the section of the form labeled
“J2 Input”, use dropdown box to
select the input signal category of
interest: SINE or Off.
2. For SINE, use the dropdown box
to select the frequency
- 1M
- 5M
- 10M
3. Click the Apply button.
Configure SINE Input on
J2
CLI n/a n/a
Front Panel n/a n/a
