66 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Chapter 3
TIME Button
TIME Button
Cycling the TIME button changes the predefined format and contents of the time
display:
Large numeric time display on full screen. Hours:Minutes:Seconds
Medium numeric time display on the left, current reference and NTP Stratum on the
right
Small date and time, reference, and NTP stratum.
The time display also indicates a time scale:
If the time zone setting on the TIMING - Time Zone web page is set to UTC, the time
display shows "UTC" as the time scale.
If the time zone setting on TIMING - Time Zone page is set to a non-UTC (local)
time zone, the time display leaves the time scale blank, or adds AM/PM if the user
selects the 12-hour time scale. (Press the MENU button and select 2) Display > 3)
12/24 > 1) 12 (AM/PM).
If the Ignore UTC Corrections from GPS Reference setting on the TIMING - HW
Clock page is enabled (selected), the time display shows "GPS" as the time scale.
Note: The TIMING - Time Zone page configures the display for UTC or local time.
The TIMING -
STATUS Button
Pressing the STATUS button repeatedly displays a series of status screens for:
NTP
Alarms
Network Ports
Clock
GNSS Receiver
SyncServer model, serial number, software version, and software upgrade
availability. If installed, the configuration for each port of the timing/IO module.
