286 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Appendix B Specifications and Factory Defaults
GNSS Antenna Kits Specifications
GNSS L1 Inline Amplifier Specifications
The GNSS L1 Inline Amplifier (112-00076-000) option boosts the signal from the
antenna. Use this amplifier on longer cable runs to maintain sufficient gain; it
receives power from the GNSS radio receiver through the antenna coaxial cable
connections. Table B-26 provides mechanical and electrical specifications for the
amplifier.
Table B-26. GNSS L1 Inline Amplifier Specifications
Characteristic Specification
Mechanical
Connectors, (In/Out) N-Type
Dimensions, includes connectors Length: 2.32 in (59 mm)
Operating Temp. -40 to +85 C
Environmental RoHS, REACH, and IP67
Electrical
Nominal Gain 25 dB +4/-0 dB typical
Pass Band Ripple ± 2 dB
Impedance 50 Ohms
Noise Figure 2 dB typical
Bandwidth 1.2 to 1.8 GHz
Input VSWR 1.5 typical / 2 maximum
Output VSWR 1.5 typical / 2 maximum
Reverse Isolation >35 dB
Output 1 dB -10 dB
Output 3 dB +5 dBm
