PRECAUTIONS IN PREPARING DATA WITH REGISTER MARK
5-7
Example of cause of wrong detection1:
Layer of the offset printingis misaligned .
Example of cause of wrong detection2:
The diarnce between square marks (TP3 of pattern A and TP1 of pattern C, or TP2 of pattern A and TP1 of
patternB) is less than 10mm.
• When printing with offset, square mark is printed in one color.
Detectedmarkorigin
Markorigin
TP1
TP1
TP2
TP2 TP1 TP2
TP3
TP3
TP4
TP4
PatternCPatternC
PatternA
PatternA PatternBPatternB
Morethan10mm
Morethan10mm
