MIMAKI CF2 Series User Manual

SETTING CUTTING CONDITIONS [CONDITION]
2-25
Set values
Plotting conditions for pens
Set values for plotting conditions are given below.
Set values
Speed: 0.2, 0.5, 1, 2, 5, 10, 15, 20, 25, 30, 40, 45, 50 (cm/s)
Pressure: 20 to 100 (in increments of 5 g)
100 to 400 (n increments of 10 g)
Acceleration: 0.1 to 0.3 (in increments of 0.1 G)
R5 speed: Off, 1, 2 (cm/s)
R10 speed: Off, 1, 2, 3, 4, 5 (cm/s)
R15 speed: Off, 1, 2, 3, 4, 5, 10 (cm/s)
R20 speed: Off, 1, 2, 3, 4, 5, 10, 15 (cm/s)
R30 speed: Off, 1, 2, 3, 4, 5, 10, 15, 20 (cm/s)
R40 speed: Off, 1, 2, 3, 4, 5, 10, 15, 20, 25 (cm/s)
R50 speed: Off, 1, 2, 3, 4, 5, 10, 15, 20, 25, 30 (cm/s)
R100 speed: Off, 1, 2, 3, 4, 5, 10, 15, 20, 25, 30 (cm/s)
Cutting conditions for the tangential cutter
Set values for the tangential cutter are given below.
The tangential cutter comes in two different types, a cutter attached to unit C, and a reciprocal cutter (vibration
cutter) attached to unit B.
Set values
Speed: 0.2, 0.5, 1, 2, 5, 10, 15, 20, 25, 30, 35, 40, 45, 50 (cm/s)
Pressure: 500 to 1500 (in increments of 100 g) Low-pressure cutter
1000 to 5000 (in increments of 100 g) High-pressure cutter
Fixed to 1500 g (reciprocal cutter)
Acceleration: 0.1 to 0.5 (in increments of 0.1 G)
Start correction: 0.00 to 2.50 (in increments of 0.05 mm)
End correction: 0.00 to 2.50 (in increments of 0.05 mm)
Up angle: 0 to 180 (in increments of 1°)
Ring distance: 0.00 to 2.50 (in increments of 0.05 mm)
Press correction: 0 to 500 (in increments of 100 g)
VIBRATION: 1 to 5 or OFF (unit B only)
R5 speed: Off, 0.5 (mm/s), 0.1, 0.2, 0.5, 1.0, 2.0 (cm/s)
R10 speed: Off, 0.5 (mm/s), 0.1, 0.2, 0.5, 1.0, 2.0 (cm/s)
R15 speed: Off, 0.5 (mm/s), 0.1, 0.2, 0.5, 1.0, 2.0 (cm/s)
Marking conditions for the crease roller
The following gives set values for crease conditions for the crease roller.
Set values
Speed: 0.2, 0.5, 1, 2, 5, 10, 15, 20, 25, 30 (cm/s)
Pressure: 1000 to 5000 (in increments of 100 g)
Acceleration: 0.1 to 0.3 (in increments of 0.1 G)
Up angle: 0 to 180 (in increments of 1°)
Ring distance: 0.00 to 2.50 (in increments of 0.05 mm)
VIBRATION Vibration speed can be set to 5 levels. Normally, set the
vibration speed to 4 or 5. Works that are easily affected by
heat should be cut using a lower vibration speed. When
using cutter holder 2N, set the vibration to “OFF.”
○
Setting item Description Pen
Tangential
cutter
Crease
roller
Swivel
blade
