REMOTE mode and the indications on the LCD
Under the REMOTE mode, cutting or plotting can be carried out in accordance with data received.
The LCD indicates cutting (plotting) conditions and the capacity of data received.
Capacity of data decreases as you proceeds with cutting (plotting). The POWER ON key, the POWER OFF
key, the key and the key are operative.
Under the REMOTE mode, the following three different indications are shown on the LCD.
When the tangential cutter or marking roller is selected:
This REMOTE screen appears when [HEAD: C] and [TOOL: CUTTER1 OR CUTTER2] have been selected
for the TOOL SELECTION in the LOCAL MENU.
If the marking roller has been selected, F (start correction) and E (end correction) are not displayed.
When selecting a pen
This REMOTE screen appears when [HEAD : A] and [TOOL : PEN] have been selected for the
TOOL SELECTION in the LOCAL MENU.
When selecting an eccentric cutter
This REMOTE screen appears when [HEAD : A] and [TOOL : ECCENTRIC CUTTER] have been
selected for the TOOL SELECTION in the LOCAL MENU.
［REMOTE］ ０ Ｋ Ｂ
TANGENTIAL BLD １
Ｓ ３０ Ｐ １５００ Ｒ ０．３０
Ｈ ３ ０ Ｆ ０．０ ０ Ｅ ０．０
S: Cutting speed
R: Rounding-off distance
F: Start correction
P: Cutting pressure
H: Cutter lifting angle
E: End correction
［REMOTE］ ０ Ｋ Ｂ
PEN
Ｓ３０ Ｐ２００
S: Cutting speed P: Cutting pressure
［REMOTE］ ０ Ｋ Ｂ
SWIVEL BLD
Ｓ ３ ０ Ｐ １ ２ ０ Ｏ ０ ．３ ０
S: Cutting speed P: Cutting pressure
O: Offset value
