3-15
TROUBLESHOOTING
Corrective measures against troubles in the case where no error message is given on the LCD are described in this
section.
Refer to the description given in “Troubles for which error messages are given on the LCD” in Chapter 3 for a trouble
that is not covered in this section and accompanied by the indication of an error message on the LCD.( P. 3-17)
The device not at all actuates even when the power to the device is turned on
The device fails to actuate even when data is transmitted from CAD
Error arises when transmitting data
The tool drags on the sheet of paper
Cause Corrective measure Reference page
Cause Corrective measure Is the power cable
securely connected to the device?
Properly connect the power cable to the device.
P. 1-12
Properly connect the power cable to the device. Release the EMERGENCY switch from the
pressed state.
P. 1-16
Cause Corrective measure Reference page
Is the device set in the LOCAL mode? Set the device to the REMOTE mode.
P. 1-17
Is the interface cable securely connected to the
device?
Properly connect the interface cable to the
device.
P. 1-11
Cause Corrective measure Reference page
Do communication conditions match those on the
computer?
Adjust the communication conditions to those
on the computer.
P. 1-19
Do commands on the computer match those on
the plotter?
Adjust the commands on the plotter to those on
the computer.
P. 1-24
Cause Corrective measure Reference page
Is there any wrinkle or warpage on the sheet of
paper?
Smooth down the sheet of paper to remove
wrinkles and warpages.
P. 2-9
Is the height of the head excessively low? Properly adjust the height of the head to the
thickness of the work used.
P. 2-19
Is the lifting/lowering movement of the pen
defective?
Turn the power off. Then, move the head A up
and down. If the head fails to go up and come
down normally, please contact your local
dealer or MIMAKI office.
―
To Next Page
