1-2
INSTALLATION SITE
Install the device at a place where the below-stated installation area is provided.
Installation area (CF2-0912)
Installation area (CF2-1215)
• Place nothing within an installation area. If a thing is placed, the risk of tripping over will be
caused.
• Place this device in a well ventilated area. If this device is used in a closed space, the blower
exhaust and the reciprocal exhaust may cause the operator to feel unwell.
• The distance between the floor and the ceiling must be at least 2300 mm.
1000mm 1000mm
1000mm
1000mm
3595mm
37571mm
1000mm 1000mm
1000mm
1000mm
3895mm
4057mm
