7-15
D. SPECIFICATIONS
Basic specifications
*1 This is the accuracy for pen writing with almost no load. The guaranteed temperature range is 20 to 25C.
*2 This is the maximum thickness of works that can be set. This value differs from the maximum thickness that can be cut.
*3 This is a dedicated HP-GL command.
Type CF2-0912 CF2-1215 CF2C-1218
Effective stroke X axis 1200 1500 1800
Y axis 900 1200
Driving method X, Y, Z, θ 4-axis DC software servo
Maximum speed 50 cm/s
Maximum acceleration 0.5 G
Mechanical resolution X axis : 0.00234375 mm, Y axis : 0.003125 mm, θ axis : 0.05625°
Command resolution 0.025 mm / 0.01 mm (switchable on operation panel)
Static accuracy
*1
Range accuracy ±0.1 mm or ±0.1% of travel distance, whichever is largest
Repeat accuracy ±0.1 mm
Origin reproduc-
ibility
±0.1 mm
Perpendicular
accuracy
0.7 mm 0.9 mm
Work securing method Vacuum suction by blower
Maximum set work thickness
20 mm
*2
Settable work weight 70 kg max. (point load)
Receiving buffer capacity 1MB
Command
MGL-IIc3 (MGL-IIc supported)
*3
Interface RS-232C
Packing configuration Main unit and pedestal separated and packed in one box; blower packed
in separate box
External
dimensions
Width 1757 2057 2357
Depth 1595 1895
Height 1100 (except cable guide)
Cutting panel sur-
face height
Approx. 770
Main unit weight 140 165 180
Operating environment 5 to 40C, 35 to 75% (Rh), no condensation
Input power supply Main unit : 50/60 Hz AC 100/120/220/240V(tap changing)
Power consumption Main unit : Less than 500VA Blower : Stated separately
