Page #107 background imageLoading...
Page #107 background image
TROUBLES FOR WHICH ERROR MESSAGES ARE GIVEN ON THE LCD
3-19
Errors that cannot be corrected by users
If any of the errors described below has arisen, immediately turn of the power to the device.
Wait for a while and re-turn on the power to the device. If the same message appears on the LCD, immediately turn
the power off and contact your local dealer or MIMAKI office.
(*1) " ERROR 70 θ OVERLOAD " occurs when the head height is too excessive, and also when θ rotation
was performed without the tool of unit B reaching the work.
If " ERROR 70 θ OVERLOAD " occurs when the data is sent again after the tool is lowered until it
reaches the work, contact your local dealer or MIMAKI office.
Error message Error message
ERROR 00 MAIN ROM ERROR 42 X OVERCURRENT
ERROR 01 SERVO ROM ERROR 43 Y OVERCURRENT
ERROR 02 MAIN RAM ERROR 46 PEN SENSOR
ERROR 03 SERVO RAM ERROR 50 X SENSOR
ERROR 04 EEPROM ERROR 51 Y SENSOR
ERROR 05 HANDSHAKE ERROR 52 θ ORIGIN
ERROR 06 BUFFER ERROR 53 Z ORIGIN
ERROR 08 POWER ERROR 70 θ OVERLOAD
ERROR 12 DEVICE ERROR 20 ERROR 71 θ OVERCURRENT
ERROR 20 I/O ERROR 72 CUTTER Z LOAD
ERROR 40 X OVERLOAD ERROR 73 ROLLER Z LOAD
ERROR 41 Y OVERLOAD ERROR 90 F/W
