INSTALLATION SITE
1-3
Installation area (CF2-1218)
Blower installation area
Set the blower under the main unit.
• The exhaust temperature reaches high levels. Do not place easily flammable materials in the
direction of the exhaust.
• The exhaust temperature can rise as high as 140°C. Since the temperature remains high even
after the blower is stopped, be careful not to get burned.
1000mm 1000mm
1000mm
1000mm
3895mm
4357mm
To Next Page
